60-TRV-XT-XL– 3 Sided Electric Fireplace

60″ Extra Tall Electric Fireplace- 14 1/4″ in depth with 3 sided glass fireplace

Description

60-TRV-XT-XL – 60″ wide x 22″ in height – 3 sided glass / indoor or outdoor electric fireplace

Amantii electric fireplace


REACHING NEW HEIGHTS

The 60-TRV-XT-XL electric fireplace features an Extra Tall viewing area that is 22” in height! That is 6” taller than our other Tru-View models. It has a deep media tray and comes standard with an incredible 15 piece log set, ICE media, pebbles, stones, black glass and vermiculite embers allowing consumers to completely customize the look of their fireplace. The 60-TRV-XT-XL electric fireplace boasts the Amantii FIRE & ICE® Flame presentation with three color LED light strips allowing for multi-color flame options. With just a click of the included remote control, choose from blue, rose, violet, yellow or orange colored flames.

Corner Fireplace: The TRV-XT-XL series work beautifully as Corner Electric Fireplace. Also rated as an outdoor electric fireplace.

The 60-TRV-XT-XL comes standard with a 15 piece log set, ICE media, pebbles, stones, black glass and vermiculite embers.

KEY FEATURES
Glass viewing area is 22” in height electric fireplace mood lighting Illuminate decorative media like never before with ambient canopy lighting in 13 colors
indoor - outdoor fireplace Rated for either indoor or outdoor use Fire and Ice media Comes with a Designer Media Kit which includes a 15 piece log set, ICE media, pebbles, stones, black glass and vermiculite embers.
Hardwire ready electric fireplace Thermostat hard-wire ready
Electrical hard-wire ready
electric fireplace zone heating  Perfect for zone heating approx. 400-500 sq ft.
4800 BTU
Fire & Ice® Flame Presentation FIRE & ICE® Flame Presentation  – Three light strips allow for yellow, orange, blue, violet & rose colored flames fireplace heater and fan Heater & Fan
Flame operates with or without heat
FEATURES
  • Incredible 3 sided glass viewing area
  • All models are rated for either indoor or outdoor use
  • State‐of‐the‐art FIRE & ICE ® flame set, with a click of the remote, change the flame from traditional colors such as yellow and orange to more contemporary colors like blue, purple, rose and violet.
  • Can produce up to 4800 BTU of heat, enough to heat up to 500 sq feet
  • 2 Stage heater
  • Hard‐wire ready
  • Thermostat hard‐wire ready
  • Flame operates with or without heat
  • Remote control for flame and heater
  • 2 flame sets
  • Ambient canopy lighting in 13 colors illuminates media like never before
4 INSTALLATION OPTIONS:
  • all 3 sides of glass visible
  • Left side visible
  • Right visible
  • front only for an extra deep (14 1/4″) fireplace

4 installation methods for Tru_View fireplaces


This corner fireplace can open left or open right or can have 3 sides open.corner electric fireplace


Customize the appearance of the 60-TRV-XT-XL further by utilizing the included Designer Media Kit which includes a 15 piece log set, ICE media, pebbles, stones, black glass and vermiculite embers. Further media options available for additional purchase. TRV-XL-XT fireplaces are rated for Indoor or Outdoor use. For outdoor applications please follow these instructions.

FIRE & ICE® flame presentation Ambient Canopy Lighting
Tru-View Fire & Ice® Flame Presentation
Vibrant multi-colored state-of-the-art FIRE & ICE® flame that is easily changed from blue to purple to rose to violet to orange or yellow with just a click of the remote. Three color strips generate more flame options that ever.
Canopy Lighting for BI-DEEP models
Ambient canopy lighting illuminates media like never before. Cast a colorful glow over the supplied decorative media in the tray below. Cycle through a rainbow of 13 different colors. Blend flame colors with contrasting canopy lighting for a unique presentation – the combinations are limitless.
INCLUDED MEDIA & ACCESSORIES

The 50-TRV-XT-XL electric fireplaces come with your choice of: Driftwood, Birch or Rustic Log media kits OR ICE media kit.

SYM-XT accerssories

DISCLAIMER:
Flames and flame colors on the website may appear differently in real life.


Specs

60-TRU-VIEW-XL-XT
Volts 120
Amps 12.5
Watts 1500 max
Heater 1500 watts high
750 watts low
No Heater 19 watts

Lamps LED  – 54 watts
Rotor Motor 2 at 5 watts
Height, Width, Depth 33” x 63 1/4” x 13 3/4”
Glass View Opening 22” X 59 5/8”
Glass Size 22” X 59 5/8”
Shipping Size 35 1/4” x 67 1/2” x 15 5/8”
Shipping Weight 169.8 lbs – glass included
150.4 lbs – unit
Plug Location Left Side
Cord Length 76″
Approx. Heating Area 400 sq. ft.

DISCLAIMER:
Flames and flame colors on the website may appear differently in real life.


Manufacturer's Documentation

BROCHURE – English

BROCHURE – metric

BROCHURE -Français

SPECS

MANUAL

INSTALLATION INSTRUCTIONS

OUTDOOR INSTALLATION INSTRUCTIONS

TRU View XL Drill Modifications Diagram

REPLACEMENT GLASS MEASUREMENTS
